The Gibson collection gives contemporary industrial design a softer point of view. The tubular spout and handles mirror the look of exposed piping while polished edges to create a chic and Modern style.

Specification:
Connection Size : 1/2"
Connection Type : IPS
Showerhead Flow Rate : 1.75 Gpm (6.65 L/Min) Max.
Showerhead Functions : Six-Function
Showerhead Size : 4.5" Diameter Spray Head
Showerhead Type : Standard
Spout Connection Type : IPS
Spout Length : 6 1/2"
Tub Spout Type: Diverter

Benefits
-Spot Resist™ brushed nickel finish resists fingerprints and water spots for a cleaner looking bath
-Lever handle makes it easy to adjust the water
-Install with Posi-Temp® pressure balancing control valve to maintain water temperature control in the shower
-4.5" diameter spray head
-6 1/2" tub spout length
-Limited lifetime warranty

DESCRIPTION
• Component construction with various finishes identified by suffix
• Pressure balancing cycle valve design with an adjustable temperature limit stop
• 1/2" IPS/CC connections
• Includes valve, showerhead, tub spout, arm and flange
OPERATION
• Lever style handle
• Handle operates counterclockwise through a 270˚arc with off
at 6 o’clock and maximum hot at the 9 o’clock position. Shut off in clockwise direction
• Adjustable temperature limit stop to control maximum hot water temperature
• Pressure balancing mechanism maintains selected discharge temperature to ± 2°
FLOW
• Designed to deliver 1.75 gpm (6.6 L/min)
(for models manufactured after 3/1/18)
• Designed to deliver 2.5 gpm (9.5 L/min)
(for models manufactured before 3/1/18)
STANDARDS
• Third party certified to ASME A112.18.1/CSA B-125.1 and all applicable
requirements referenced therein
• ADA for lever handle
• Meets WaterSense® criteria
• Meets New York City Local Law No. 57
• Products marked with 1.75 gpm are comp
